FORESTADENT PALATAL EXPANDERS

Flat Spring
Snap-Lock
EXPANSION SCREWS
Expander

Spindle
1. Activation in progress.
(Spring under tension)

The Key to Safe and Efficient Expansion Flat Spring
· The Snap Lock Expander does not turn back unless the doctor or patient turns it back.
After the activation of the spindle (Fig 1), the flat spring snaps in (Fig 2).
· The hole in the spindle is always in the right place for reactivation.
· When the Snap Lock Expander is properly activated by 1/4 turn, both the patient and
doctor will be able to feel the screw lock. Spindle
· If overactivated, the Snap Lock Expander can be turned back. 2. Start and final position,
ready for reactivation.
The spring pushes the excentric spindle. This makes the spindle Spring in locked position.
snap into an ideal position for reactivation and locks it.

Each screw comes with one stainless steel activation key. Expansion Per Turn Dimensions Item #
8 mm 0.9 mm 12 mm A167-123
Individually .................................... 28.95 ea. 10 mm 0.9 mm 14 mm A167-143
$
10 or more ...................................... 27.95 ea.
$
50 or more ...................................... 26.95 ea. 12 mm 0.9 mm 16 mm A167-163
$

Each screw comes with one
stainless steel activation key.

Without Legs Anatomical Palatal Split Screw ‘S’ Anatomical Palatal Split Screw ‘N’
10 mm expansion 12 mm expansion
Palatal Split Screw 0680-010 0680-01A
10 mm expansion · For narrow palates. · Pre-bent arms are set inside the body of
0680-020 · Pre-bent arms. the screw for strength during expansion.
· For narrow palates. · Perfect anatomical design for increased · Perfect anatomical design for increased
· Can be placed in acrylic. patient comfort. patient comfort.
Individually ................ 14.95 ea. Individually ................ 21.95 ea. Individually ................ 18.95 ea.
$
$
$
10 or more .................. 13.95 ea. 10 or more .................. 20.95 ea. 10 or more .................. 17.95 ea.
$
$
$
50 or more .................. 12.95 ea. 50 or more .................. 19.95 ea. 50 or more .................. 16.95 ea.
$
$
$
Slim Line
Expanders
Ideally suited for upper and lower arch development in which arch width is required. Other applications
include expansion, distalization and torquing of molars. Length: 16mm Arm Length: 60mm. 8mm or 12mm
o
expansion. One complete turn of 360 = 0.8mm of expansion. Stainless steel key included with each screw.
Individually ................ 25.95 ea.
$
$
8mm expansion .............................1981-223 10 or more .................. 25.45 ea.
$
12mm expansion ...........................1981-623 50 or more .................. 24.95 ea.
